Brewtools - Density / Temp. Sensor, TC 1.5" 300mm
Price:
€358.80
Tax included
In stock - Ready to ship
- Dedicated advice and support
- After-sales service
- Fast shipping
- Secure payments
Description
With this Brewtools sensor, monitor the evolution of your gravity live through the Fluid Control System.
Improve your fermentation monitoring with this density sensor equipped with a temperature probe. Using advanced tuning fork technology, it provides highly accurate, real‑time measurements of density and temperature directly from your fermenter.
By vibrating the tuning fork and analyzing its resonant frequency, the sensor calculates specific gravity (SG) with remarkable precision. This gives you reliable tracking of your fermentation, allowing you to make informed decisions about your brew.
Designed for Brewtools F40 to F300 fermenters, it is also fully compatible with other conical fermenters such as BrewBuilt Unitanks. This 300 mm Tri‑Clamp model integrates perfectly into your setup. Accuracy may vary in smaller vessels, but pressure fermentation can improve results.
When paired with the Brewtools FCS system, it enables full data logging and scalable control. Future software updates will even allow temperature and pressure step management based on density, reducing the need for manual intervention.
This sensor helps you take your fermentation to the next level with data‑driven insight, consistency, and repeatability.
* To calibrate and configure your sensor, refer to the manual available in the “downloads” tab of this product.
See more
Main Features:
- - Dual measurement: real-time density and temperature
- - Tuning fork technology for high accuracy and reliability
- - Probe length: 300 mm — ideal for large-capacity tanks
- - 1.5″ Tri‑Clamp fitting, minimum port Ø25 mm
- - Designed for Brewtools, also compatible with BrewBuilt and other Unitanks
- - Compatible with Brewtools FCS for logging and control
Specifications:
- - Density accuracy: ±0.002 SG
- - Temperature accuracy: ±0.3 °C
- - Flange: 1.5″ Tri‑Clamp
- - Length: 300 mm from flange
- - Connector: LP12 5‑pin (CAN bus + 24 V)
Important Note:
Accuracy can be affected by several factors: yeast health, trub content, flocculation, rapid temperature changes, dry hopping, or proximity to heating elements. Performance and features will continue to improve through software updates.
Refer to the “downloads” tab to access the user manual (+FAQ) for this product.
